Brand: AVEMIAModel number: MG4C5G4B |
AVEMIA MG4C5G4B |
DVR Features:
* 500gb Hard Drive
* HDMI Output
* 960H Real Time preview, recording and playback
* Remote View by PC & Smartphone
* P2P function, simple and easy set up
DVR Specifications:
* Video Input Channel-4 BNC
* Video Output Channel-1 BNC Out
* VGA Output Channel-1 VGA Output
* HDMI Output Channel-1 HDMI Output (up to 1920 x1080)
* Audio In-4 RCA
* Audio Out-1 BNC
* Display Resolution per Channel-960x480-30 fps
* Resolution Recording -CIF-120 fps, D1-120 fps, 960H-120fps
* Recording Modes-Manual, Scheduled, Sensor, Motion trigger
* Recording Compression-H.264
* Storage-Up to 6TB, SATA interface HDD x2
* Backup Device-USB drive
* Alarm Input-4
* Alarm Output-1
* Serial Connectors-2 USB 2.0
* Network Connection-10/100 Ethernet(RJ-45)
* Network Protocol-TCP/IP, Static IP, DHCP, DDNS
* Network Remote-IE, Firefox, Chrome & Smartphone
* Playback-Via Client Player
* Supply Voltage-12VDC 4Amp
* Dimension (W x L x H)-330 x260 x50mm
Camera Features:
* 1/3" Pixel Plus CMOS Image Sensor
* 700 TV Lines
* 24IR, 0 LUX (IR On)
Camera Specifications:
* Image Sensor 1/3" Pixel Plus CMOS Image Sensor
* Signal System- NTSC
* Effective Pixels- 1020(H) x 596(V)
* Horizontal Resolution- 700 TV Lines
* Minimum Illumination- 0 LUX (IR on)
* IR Distance- 24 LEDs, up to 60ft
* Electronic Shutter- 1/60 - 1/100,000 sec
* S/N Ratio- >60dB
* Video Output- 1.0Vp-p, 75ohms
* Supply Voltage- DC 12V (±10%)
* Mounting Lens- 3.6mm
* Power Consumption- Min Req:500mA / Recommended:1A
* Housing- Aluminum Alloy
